java netty 实现 websocket 服务端和客户端双向通信 实现心跳和断线重连 完整示例

maven依赖


    io.netty
    netty-all
    4.1.97.Final

服务端

一个接口 IGetHandshakeFuture

package com.sux.demo.websocket2;

import io.netty.channel.ChannelPromise;

public interface IGetHandshakeFuture {
    ChannelPromise getHandshakeFuture();
}

服务端心跳 ServerHeartbeatHandler

package com.sux.demo.websocket2;

import io.netty.channel.ChannelHandlerContext;
import io.netty.channel.ChannelInboundHandlerAdapter;
import io.netty.handler.codec.http.websocketx.PongWebSocketFrame;
import io.netty.handler.timeout.IdleState;
import io.netty.handler.timeout.IdleStateEvent;

public class ServerHeartbeatHandler extends ChannelInboundHandlerAdapter {
    @Override
    public void userEventTriggered(ChannelHandlerContext ctx, Object evt) throws Exception {
        if (evt instanceof IdleStateEvent) {
            IdleStateEvent event = (IdleStateEvent) evt;
            if (event.state() == IdleState.READER_IDLE) { // 读空闲
                // System.out.println("关闭客户端连接, channel id=" + ctx.channel().id());
                // ctx.channel().close();
            } else if (event.state() == IdleState.WRITER_IDLE) { // 写空闲
                System.out.println("服务端向客户端发送心跳");
                ctx.writeAndFlush(new PongWebSocketFrame());
            } else if (event.state() == IdleState.ALL_IDLE) { // 读写空闲

            }
        }
    }
}

服务端封装 WebSocketServer

package com.sux.demo.websocket2;

import io.netty.bootstrap.ServerBootstrap;
import io.netty.channel.*;
import io.netty.channel.nio.NioEventLoopGroup;
import io.netty.channel.socket.SocketChannel;
import io.netty.channel.socket.nio.NioServerSocketChannel;
import io.netty.handler.codec.http.HttpObjectAggregator;
import io.netty.handler.codec.http.HttpServerCodec;
import io.netty.handler.codec.http.websocketx.WebSocketServerProtocolHandler;
import io.netty.handler.timeout.IdleStateHandler;

import java.util.concurrent.TimeUnit;

public class WebSocketServer {
    private EventLoopGroup bossGroup;
    private EventLoopGroup workerGroup;

    public WebSocketServer() {
        //创建两个线程组 boosGroup、workerGroup
        bossGroup = new NioEventLoopGroup();
        workerGroup = new NioEventLoopGroup();
    }

    public void start(int port, WebSocketServerHandler handler, String name) {
        try {
            //创建服务端的启动对象，设置参数
            ServerBootstrap bootstrap = new ServerBootstrap();
            //设置两个线程组boosGroup和workerGroup
            bootstrap.group(bossGroup, workerGroup)
                    //设置服务端通道实现类型
                    .channel(NioServerSocketChannel.class)
                    //设置线程队列得到连接个数
                    .option(ChannelOption.SO_BACKLOG, 128)
                    //设置保持活动连接状态
                    .childOption(ChannelOption.SO_KEEPALIVE, true)
                    //使用匿名内部类的形式初始化通道对象
                    .childHandler(new ChannelInitializer() {
                        @Override
                        protected void initChannel(SocketChannel socketChannel) throws Exception {
                            //给pipeline管道设置处理器
                            socketChannel.pipeline().addLast(new HttpServerCodec());
                            socketChannel.pipeline().addLast(new HttpObjectAggregator(65536));
                            socketChannel.pipeline().addLast(new WebSocketServerProtocolHandler("/websocket"));
                            socketChannel.pipeline().addLast(new IdleStateHandler(5, 2, 0, TimeUnit.SECONDS));
                            socketChannel.pipeline().addLast(new ServerHeartbeatHandler());
                            socketChannel.pipeline().addLast(handler);
                        }
                    });//给workerGroup的EventLoop对应的管道设置处理器
            //绑定端口号，启动服务端
            ChannelFuture channelFuture = bootstrap.bind(port).sync();
            System.out.println(name + " 已启动");
            //对通道关闭进行监听
            channelFuture.channel().closeFuture().sync();
        } catch (InterruptedException e) {
            e.printStackTrace();
        } finally {

        }
    }
}

服务端消息处理 WebSocketServerHandler

package com.sux.demo.websocket2;

import io.netty.buffer.Unpooled;
import io.netty.channel.*;
import io.netty.handler.codec.http.websocketx.*;
import io.netty.util.CharsetUtil;

import java.util.ArrayList;
import java.util.List;

@ChannelHandler.Sharable
public class WebSocketServerHandler extends SimpleChannelInboundHandler {

    private List channelList;

    public WebSocketServerHandler() {
        channelList = new ArrayList();
    }

    public boolean hasClient() {
        return channelList.size() > 0;
    }

    @Override
    protected void channelRead0(ChannelHandlerContext ctx, Object msg) {
        if (msg instanceof PingWebSocketFrame) {
            System.out.println("收到客户端" + ctx.channel().remoteAddress() + "发来的心跳：PING");
        }

        if (msg instanceof TextWebSocketFrame) {
            TextWebSocketFrame frame = (TextWebSocketFrame) msg;
            System.out.println("收到客户端" + ctx.channel().remoteAddress() + "发来的消息：" + frame.text());
            /*for (Channel channel : channelList) {
                if (!ctx.channel().id().toString().equals(channel.id().toString())) {
                    channel.writeAndFlush(new TextWebSocketFrame(Unpooled.copiedBuffer(frame.text(), CharsetUtil.UTF_8)));
                    System.out.println("服务端向客户端 " + channel.id().toString() + " 转发消息：" + frame.text());
                }
            }*/
        }
    }

    @Override
    public void channelActive(ChannelHandlerContext ctx) throws Exception {
        channelList.add(ctx.channel());
        System.out.println("客户端连接：" + ctx.channel().id().toString());
    }

    @Override
    public void channelInactive(ChannelHandlerContext ctx) throws Exception {
        channelList.remove(ctx.channel());
    }

    @Override
    public void channelReadComplete(ChannelHandlerContext ctx) throws Exception {
        ctx.flush();
    }

    @Override
    public void exceptionCaught(ChannelHandlerContext ctx, Throwable cause) throws Exception {
        ctx.close();
        channelList.remove(ctx.channel());
    }

    public void send(String text) {
        for (Channel channel : channelList) {
            channel.writeAndFlush(new TextWebSocketFrame(Unpooled.copiedBuffer(text, CharsetUtil.UTF_8)));
        }
    }
}

服务端测试主机 WebSocketClientHost

package com.sux.demo.websocket2;

import io.netty.buffer.Unpooled;
import io.netty.channel.Channel;
import io.netty.handler.codec.http.websocketx.TextWebSocketFrame;
import io.netty.util.CharsetUtil;

public class WebSocketClientHost {
    public static void main(String[] args) {
        WebSocketClient webSocketClient = new WebSocketClient();

        SendDataToServerThread thread = new SendDataToServerThread(webSocketClient);
        thread.start();

        webSocketClient.connect("127.0.0.1", 40005, "WebSocket客户端");
    }
}

class SendDataToServerThread extends Thread {
    private WebSocketClient webSocketClient;

    private int index = 1;

    public SendDataToServerThread(WebSocketClient webSocketClient) {
        this.webSocketClient = webSocketClient;
    }

    @Override
    public void run() {
        try {
            while (index

客户端

客户端心跳 ClientHeartbeatHandler

package com.sux.demo.websocket2;

import io.netty.channel.ChannelHandlerContext;
import io.netty.channel.ChannelInboundHandlerAdapter;
import io.netty.handler.codec.http.websocketx.PingWebSocketFrame;
import io.netty.handler.timeout.IdleState;
import io.netty.handler.timeout.IdleStateEvent;


public class ClientHeartbeatHandler extends ChannelInboundHandlerAdapter {
    @Override
    public void userEventTriggered(ChannelHandlerContext ctx, Object evt) {
        if (evt instanceof IdleStateEvent) {
            IdleStateEvent event = (IdleStateEvent) evt;
            if (event.state() == IdleState.READER_IDLE) { // 读空闲
                System.out.println("断线重连");
                ctx.channel().close();
            } else if (event.state() == IdleState.WRITER_IDLE) { // 写空闲
                System.out.println("客户端向服务端发送心跳");
                ctx.writeAndFlush(new PingWebSocketFrame());
                // ctx.writeAndFlush(new TextWebSocketFrame(Unpooled.copiedBuffer("PING", CharsetUtil.UTF_8)));
            } else if (event.state() == IdleState.ALL_IDLE) { // 读写空闲

            }
        }
    }
}

客户端封装 WebSocketClient

package com.sux.demo.websocket2;

import io.netty.bootstrap.Bootstrap;
import io.netty.channel.Channel;
import io.netty.channel.ChannelFuture;
import io.netty.channel.ChannelInitializer;
import io.netty.channel.nio.NioEventLoopGroup;
import io.netty.channel.socket.SocketChannel;
import io.netty.channel.socket.nio.NioSocketChannel;
import io.netty.handler.codec.http.DefaultHttpHeaders;
import io.netty.handler.codec.http.HttpClientCodec;
import io.netty.handler.codec.http.HttpObjectAggregator;
import io.netty.handler.codec.http.websocketx.WebSocketClientHandshaker;
import io.netty.handler.codec.http.websocketx.WebSocketClientHandshakerFactory;
import io.netty.handler.codec.http.websocketx.WebSocketClientProtocolHandler;
import io.netty.handler.codec.http.websocketx.WebSocketVersion;
import io.netty.handler.timeout.IdleStateHandler;

import java.net.URI;
import java.net.URISyntaxException;
import java.util.concurrent.TimeUnit;

public class WebSocketClient {
    private NioEventLoopGroup eventExecutors;

    private Channel channel;

    public WebSocketClient() {
        eventExecutors = new NioEventLoopGroup();
    }

    public Channel getChannel() {
        return channel;
    }

    public void connect(String ip, int port, String name) {
        try {
            WebSocketClientHandshaker handshaker = WebSocketClientHandshakerFactory.newHandshaker(
                    new URI("ws://" + ip + ":" + port + "/websocket"), WebSocketVersion.V13, null, false, new DefaultHttpHeaders());
            WebSocketClientHandler handler = new WebSocketClientHandler(handshaker);
            ClientHeartbeatHandler heartbeatHandler = new ClientHeartbeatHandler();

            //创建bootstrap对象，配置参数
            Bootstrap bootstrap = new Bootstrap();
            //设置线程组
            bootstrap.group(eventExecutors)
                    //设置客户端的通道实现类型
                    .channel(NioSocketChannel.class)
                    //使用匿名内部类初始化通道
                    .handler(new ChannelInitializer() {
                        @Override
                        protected void initChannel(SocketChannel ch) throws Exception {
                            //添加客户端通道的处理器
                            ch.pipeline().addLast(new HttpClientCodec());
                            ch.pipeline().addLast(new HttpObjectAggregator(65536));
                            ch.pipeline().addLast(new WebSocketClientProtocolHandler(handshaker, true, false));
                            ch.pipeline().addLast(new IdleStateHandler(5, 2, 0, TimeUnit.SECONDS));
                            ch.pipeline().addLast(heartbeatHandler);
                            ch.pipeline().addLast(handler);
                        }
                    });

            // 连接服务端
            ChannelFuture channelFuture = bootstrap.connect(ip, port);

            // 在连接关闭后尝试重连
            channelFuture.channel().closeFuture().addListener(future -> {
                try {
                    Thread.sleep(2000);
                    System.out.println("重新连接");
                    connect(ip, port, name); // 重新连接
                } catch (Exception e) {
                    e.printStackTrace();
                }
            });

            channelFuture.sync();

            // 等待握手完成
            // IGetHandshakeFuture getHadnshakeFuture = handler;
            // getHadnshakeFuture.getHandshakeFuture().sync();

            channel = channelFuture.channel();
            System.out.println(name + " 已启动");

            //对通道关闭进行监听
            channelFuture.channel().closeFuture().sync();
        } catch (InterruptedException | URISyntaxException e) {
            e.printStackTrace();
        } finally {

        }
    }

}

客户端消息处理 WebSocketClientHandler

package com.sux.demo.websocket2;

import io.netty.channel.*;
import io.netty.handler.codec.http.FullHttpResponse;
import io.netty.handler.codec.http.websocketx.*;

@ChannelHandler.Sharable
public class WebSocketClientHandler extends SimpleChannelInboundHandler implements IGetHandshakeFuture {
    private WebSocketClientHandshaker handshaker;
    private ChannelPromise handshakeFuture;

    public WebSocketClientHandler(WebSocketClientHandshaker handshaker) {
        this.handshaker = handshaker;
    }

    public ChannelPromise getHandshakeFuture() {
        return this.handshakeFuture;
    }

    @Override
    protected void channelRead0(ChannelHandlerContext ctx, Object msg) throws Exception {
        if (!handshaker.isHandshakeComplete()) {
            try {
                handshaker.finishHandshake(ctx.channel(), (FullHttpResponse) msg);
                handshakeFuture.setSuccess();
            } catch (WebSocketHandshakeException e) {
                handshakeFuture.setFailure(e);
            }
            return;
        }

        if (msg instanceof PongWebSocketFrame) {
            System.out.println("收到服务端" + ctx.channel().remoteAddress() + "发来的心跳：PONG");
        }

        if (msg instanceof TextWebSocketFrame) {
            TextWebSocketFrame frame = (TextWebSocketFrame) msg;
            System.out.println("收到服务端" + ctx.channel().remoteAddress() + "发来的消息：" + frame.text()); // 接收服务端发送过来的消息
        }
    }

    @Override
    public void handlerAdded(ChannelHandlerContext ctx) {
        handshakeFuture = ctx.newPromise();
    }

    @Override
    public void channelActive(ChannelHandlerContext ctx) throws Exception {
        // handshaker.handshake(ctx.channel());
    }

    @Override
    public void channelInactive(ChannelHandlerContext ctx) throws Exception {

    }

    @Override
    public void channelReadComplete(ChannelHandlerContext ctx) throws Exception {
        ctx.flush();
    }

    @Override
    public void exceptionCaught(ChannelHandlerContext ctx, Throwable cause) throws Exception {
        ctx.close();
    }
}

客户端测试主机 WebSocketServerHost

package com.sux.demo.websocket2;

public class WebSocketServerHost {
    public static void main(String[] args) {
        WebSocketServerHandler handler = new WebSocketServerHandler();
        WebSocketServer webSocketServer = new WebSocketServer();

        SendDataToClientThread thread = new SendDataToClientThread(handler);
        thread.start();

        webSocketServer.start(40005, handler, "WebSocket服务端");
    }
}

class SendDataToClientThread extends Thread {
    private WebSocketServerHandler handler;

    private int index = 1;

    public SendDataToClientThread(WebSocketServerHandler handler) {
        this.handler = handler;
    }

    @Override
    public void run() {
        try {
            while (index

测试

测试一

步骤：先启动服务端，再启动客户端
现象：客户端与服务端互发消息，消息发完后，互发心跳

测试二

步骤：先启动服务端，再启动客户端，然后关闭服务端，过一会再启动服务端
现象：客户端断线重连，通信恢复，正常发消息和心跳

测试三

步骤：先启动客户端，过一会再启动服务端
现象：服务端启动后，客户端连上服务端，正常通信，互发消息，消息发完互发心跳

遇到的问题

以上测试，客户端可以收到服务端发送的心跳，但是服务端无法收到客户端发送的心跳，导致服务端触发读空闲，从而关闭连接(代码已注释掉)

登录查看全部

参与评论

昵称 登录
发布评论

评论留言

还没有评论留言，赶紧来抢楼吧~~

@2025 by 唯宠科技 蜀ICP备18000267号
浏览 2966.31 万次 点击这里给我发消息

手机查看

 返回顶部

给这篇文章打个标签吧~

棒极了 糟糕透顶 好文章 PHP JAVA JS 小程序 Python SEO MySql 确认
