联邦架构(Federation)通过服务注册机制实现多源数据整合,其核心组件包括:
关键特性:
pip install fastapi==0.68.0
pip install strawberry-graphql==0.151.0
pip install uvicorn==0.15.0
import strawberry
from fastapi import FastAPI
from strawberry.fastapi import GraphQLRouter
@strawberry.type
class User:
id: int
name: str
@strawberry.type
class Query:
@strawberry.field
def user(self, id: int) -> User:
return User(id=id, name=f"User{id}")
schema = strawberry.federation.Schema(
query=Query,
enable_federation_2=True
)
app = FastAPI()
app.add_route("/graphql", GraphQLRouter(schema))
@strawberry.type
class Product:
id: int
owner: User = strawberry.federation.field(external=True)
@classmethod
def resolve_reference(cls, id: int):
return Product(id=id, owner=User(id=1))
@strawberry.type
class Query:
@strawberry.field
def product(self, id: int) -> Product:
return Product.resolve_reference(id)
schema = strawberry.federation.Schema(
query=Query,
enable_federation_2=True,
extend=[User]
)
from fastapi import FastAPI
from strawberry.fastapi import GraphQLRouter
from strawberry.schema.config import FederationConfig
config = FederationConfig(
service_list=[
{"name": "user", "url": "http://user-service/graphql"},
{"name": "product", "url": "http://product-service/graphql"}
]
)
schema = federated_schema(config=config)
app = FastAPI()
app.add_route("/graphql", GraphQLRouter(schema))
schema = strawberry.federation.Schema(
query=Query,
validation_rules=[
query_depth_validator(max_depth=10),
query_complexity_validator(max_complexity=500)
]
)
问题1:联邦架构如何处理跨服务类型扩展?
答案:通过@key指令建立实体标识,使用resolve_reference方法实现跨服务数据关联。例如用户服务定义@key(fields: "id"),商品服务通过owner字段关联用户ID。
问题2:如何优化N+1查询问题?
解决方案:在resolve方法中使用DataLoader批量加载数据,将多个独立查询合并为批量查询,减少数据库访问次数。
错误1:Schema合并冲突
Error: Cannot extend type "User" because it is not defined
解决方法:
错误2:查询超时
TimeoutError: Query execution exceeded 5000ms
优化步骤:
错误3:类型验证失败
ValidationError: Field "product" argument "id" of type "Int!" is required
处理流程:
余下文章内容请点击跳转至 个人博客页面 或者 扫码关注或者微信搜一搜:编程智域 前端至全栈交流与成长
,阅读完整的文章:如何在FastAPI中玩转GraphQL联邦架构,让数据源手拉手跳探戈?
